X9-2HDMI

4Core ARM® Cortex®-A17, Dual HDMI 4K Display, MiniPCIe Slot for 4G-LTE+SIM, 64GB eMMC+128G MicroSD/TF

Featured Highlights
	ARM® Cortex®-A17 Processor
	RK3288 Chipset
	Quad-Core Mali™ T764 3D GPU Support OpenGL ES1.1/2.0/3.0, OpenVG1.1
	HDMI 2.0+HDMI Dual Display
	2GB/4GB DDR3 Memory
	16GB-64GB eMMC Storage
	Gigabit LAN, 11n or ac WiFi+BT
	3 USB 2.0, MiniPCIe for 4G-LTE modem
	Everest ES8323S Audio chip
	DC12V 2A 24W or higher wattage Power Adapter (UL/CE/FCC Certified)
	OS Support: Android 5.1, 7.1
	Applications: Set Top Box, Digital Signage, IPTV, etc.

SKU: X9-2HDMI

Specifications
Request for Info

Product specifications

Processor • ARM® Cortex®-A17 4Core up to 2.00GHz Chipset • RK3288
Graphics • Quad-Core Mali™ T764 3D GPU Support OpenGL ES1.1/2.0/3.0, OpenVG1.1 • Dual Display support Clone or extended modes • 1 x HDMI® 2.0, 4K 30Hz Graphics port • 1 x HDMI® supporting a maximum resolution of 3840x2160 30Hz Support for HDMI® 1.4 version and HDCP 2.2 Memory • 2GB DDR3 (Option: 4GB) (built-in, non-changeable)
Network • 1 x RJ45 Gigabit (10/100/1000 Mb/s) LAN • 802.11ac/n Dual-Band Wi-Fi (2.4GHz / 5.0GHz) • Bluetooth 4.1 • 1 x MiniPCIe full size slot (for WiFi+BT/4G-LTE Module with SIM pair) • 1 x SIM socket (for 3G/4G-LTE option) • Wake on LAN, PXE boot (Diskless) supported • Option: additional Gigabit LAN can be added by USB LAN module Expansion Slot • 1 x MiniPCIe full size slot (for WiFi+BT/4G-LTE Module with SIM pair)
Storage • 16GB-64GB eMMC Flash Internal Storage • 1 x TF (MicroSD) reader supports 128GB+ MicroSD/TF Card Audio • Everest ES8323S Audio chip • Support for S/PDIF Out • 1 x 3.5mm Analog Stereo Audio jack
Back Panel I/O • 3 x USB 2.0 ports • 1 x HDMI® 2.0 port • 1 x HDMI® port • 1 x LAN port • 1 x S/PDIF port • 1 x 3.5mm Audio jack • 1 x DC-In 2.5mm Power Connector • 1 x TF reader, supports 128GB+ MicroSD Card System BIOS • Watchdog supported
Systemboard • Small Form Factor • Back I/O Chassis • Nano-LX series Fanless Enclosure • Dimensions: 5.11"(W) x 5.00"(D) x 1.02"(H), Weight: 7 lb. • Color: Black
Power Supply • Power: DC12V 2A 24W Power Adapter (UL/CE/FCC Certified) • Power Cord: Standard US Power Cord included, European Power Cord available as option • Powered by PoE supported • Energy Star Compliance, Idle mode at <1W OS Support • Android 5.1, 7.1 • Optional Android 9.0 for project only (MOQ required)
Application • Set Top Box, Digital Signage, IPTV, Traffic Controller, etc. • Embedded-Longevity Environment • Operating Temperature: 0 to +55 C • Non operating temperature: -20 to +70 C • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz • Shock - Operating: 3,920 m/s2 (400G) 2ms • Shock - Non-Operating: 8,820 m/s2 (900G) 1ms • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, RoHS Certified
