Processor
• Dual Intel® Xeon Processor E5-2600 V4 Series • Option: Quad processor Xeon MP supported
Main Memory
• 32GB Quad-Channel ECC DDR4 system memory • Optional: up to 3TB system memory
|
OS and Storage Manager
• Linux OS and NAS/iSCSI WEB based Manager • Optional: Red Hat Ceph ,Solaris, Windows Server, MS Storage Server, VMware, FreeBSD, Other Open Soruce Linux.
File System
• XFS, EXT3 standard • Optional: ZFS, NTFS, or any file system supported by the x86 platform
|
Network I/O
• 4 Ethernet ports : 2 x 10Gbit SFP+, 2 x Gigabit RJ45 copper ports • Optional: Additional 4 or 8 Gigabit LAN, 10Gbit Ethernet, Fibre Channel for SAN (can be mixed) • EDR or FDR Infiniband supported
Network Service
• DHCP client/server (default is DHCP client/static) • Network Protocol: CIFS/SMB, NFS, FTP • iSCSI / NAS / SAN (Can be mixed)
|
Management Interface
• Web GUI • E-mail notification • Local Host Access via VGA and Keyboard
Remote Boot Function
• Requires NIC with PXE support on client
|
Expansion
• 4 x PCIe 3.0 x8 slots (full height, full length) • Option: up to 7 slots with different SKU MB
File Sharing
• Authorizes users to access shared folder using passwords (by default, there is one "Public" shared folder)
|
Access Control
• Allows users to access shared files for "Read Only" or "Read/Write"
Storage/RAID
• Hardware accelerated RAID controller, PCIe 3.0 16x bus • High performance sustained read and write. Unparalleled performance • Over 8,000MB/sec random write and 3,500MB/sec random read • 48 x 2.5" hot-swap drive bays for SSD/SAS/SATA 4TB, 2TB, 1TB Drive • Optional: 1 Internal 2 x 2.5" RAID drives for OS. • RAID 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60 with hot spare support (mixed configurations available)
|
I/O
• 4x USB rear connectors • VGA graphics • 6 x SATA-6G/s port, optional SAS, M.2 NVMe, DOM ports for OS • Optional: 2 additional I/O (such as COM, PS/2, TPM) supported by header or add-on
Client Support
• MS Windows® 10, 7, XP and Windows Server, Linux , FreeBSD, Solaris and Mac • Snap Shot Backup and Recovery Client Support • Active Directory, Rsync are supported
|
Remote Controls
• Power on/off, system reset + USB • IPMI, KVM over IP, Remote Power On/Off is supported
Indicators
• Power, LAN and HDD LEDs
|
Power Supply
• 1620/1200/1000W 2+1 redundant power supply • 80 Plus Platinum class, UR/FCC/CE Certified
Operating Temperature
• From 0 ºC to 40 ºC (32ºF to 104 ºF)
|
Non-Operating Temperature
• From 0 ºC to 40 ºC (32ºF to 104 ºF)
Operating Humidity
• From 10% to 90% relative humidity
|
Chassis
• 4U Rackmount Chassis • 48 x 2.5" SAS2/SATA3 How Swap Bay with single expander backplane • 7+4 (upto 11) full height slots • Optional internal 2 x 2.5" fixed drive bays for OS SSD • Dimensions: 17.2" W x 7" H x 29" D • Weight: 120 lb.
|
Warranty
• SSD, SAS and SATA-E Hard Driver carry 5 year,SATA-N carries 3 year • Base system:3 year standard parts and depot labor;lifetime toll free phone support. • Optional:3 or 5-year(total years) extended warranty with advanced parts replacement service. • Optional:7+year extended warranty service available. • On-site service is available with additional cost.
|
