SBC56-N100

85mm Tiny Size for Robot/Drone

Featured Highlights
	Intel® N-Series Processor
	Intel® Alder/Twin Lake-N Platform (SOC)
	Intel® 12th Gen. UHD Graphics, HDMI
	LPDDRS 4800Mhz 8G
	1 x M.2-2230 Nvme SSD
	1 x Realtek RTL8111 H 1 000M
	3 x USB 3.0 ,1 x Gigabit LAN, 1 x HDMI
	DC12V 5A
	OS Support: Windows 10/11, IoT, Linux
	Applications: Digital Signage, Micro Platform for Edge Computing, OpenVino®, Audio/Video PC, AI-IoT, etc.

SKU: SBC56-N100

Specifications
Request for Info

Product specifications

Processor • Intel® N100 3.40GHz 4Cores 4Threads 6M 6W • Intel® N200 3.70GHz 4Cores 4Threads 6M 6W • Intel® N95 1.70/3.40GHz 4Core 4Threads 6M 15W • Intel® N97 3.6GHz 4Cores 6M 12W Chipset • Intel® Alder Lake-N Platform (SOC)
Memory • LPDDR5 4800Mhz 8G Graphics • Intel® 12th Gen GPU
Network • 1 x Realtek RTL8111 H 1 000M Storage • 1 x M.2-2230 Nvme SSD
I/O • 3 x USB 3.2 • 1 x RJ-45 Gigabit LAN • 1 x HDMI 1.4 Power • DC 12V 5A
OS Support • Windows 11, IoT, Linux Environment • Operating Temperature: -20 to +60 C • Non operating temperature: -40 to +75 C • Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz • Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz • Shock - Operating: 3,920 m/s2 (400G) 2ms • Shock - Non-Operating: 8,820 m/s2 (900G) 1ms • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, RoHS Certified
