Processor
• Dual Intel® Xeon® Scalable Processors Gold, Silver and Brown Series • 2 x LGA-3647 Sockets
Chipset
• Intel® 620 Chipset
|
Memory
• 16 x DIMM Sockets • Dual 6-Channel ECC DDR4 system memory • Up to 1TB Memory
OS and Storage Manager
• Linux OS and NAS/iSCSI WEB based Manager • Optional: Solaris, Windows Server, MS Storage Server, VMware, FreeBSD, Other Open Soruce Linux.
|
File System
• XFS, EXT3, EXT4 • Optional: ZFS, NTFS, or any file system supported by the x86 platform
Network I/O
• 2 x Intel 10Gbit SFP+ and 2 x Intel i350 Gigabit RJ45 LAN ports • Optional: Additional Gigabit LAN, 10Gbit Ethernet, Fibre Channel for SAN (can be mixed) • EDR, FDR or 40Gbit QDR Infiniband or Ethernet Over IB
|
Network Service
• DHCP client/server (default is DHCP client/static) • Network Protocol: CIFS/SMB, NFS, FTP • iSCSI / NAS / SAN (Can be mixed)
Management Interface
• Web GUI • E-mail notification • Local Host Access via VGA and Keyboard
|
Expansion Slot
• 1 x PCIe 3.0 16x slot for OCP Mezzanine V2.0 (Type 2: 1x QSFP or 2 x QSFP+)
Remote Boot Function
• Requires NIC with PXE support on client • IPMI 2.0 with dedicated RJ45 Port • Power on/off, system reset + USB
|
File Sharing
• Authorizes users to access shared folder using passwords (by default, there is one "Public" shared folder)
Access Control
• Allows users to access shared files for "Read Only" or "Read/Write"
|
Storage/RAID
• 102 x 3.5" Hot-swap SAS/SATA and 2 x 2.5" OS How-swap drive bays • Supports SAS-12G, SAS-6G, SATA-6G Hard Drive or SSD • Hardware Accelerated RAID Controller with Expander • Supports RAID 0, 1, 5, 6, 10, 50, 60 with hot spare drives • Supports 3.5" or 2.5" hard drive or SSD (Can be mixed) • Supports PCIe SSD Module
I/O
• 2 x USB 3.0 Type-A rear connectors, 1 x USB 2.0 and 1 x USB 3.0 Headers • 1 x AST2500 VGA port, 1 x Serial COM port, 1 x Serial Header • 4 x SATA-6G/s (SFF-8643), 2 SATA-6G/s SATA ports • SAS/ SATA Lewisburg PCH on-chip solution Backplane: • 3 x 24-port SAS-12G with 36-Phy expander and 2 x 8i SAS Slimline connectors • 1 x 30-port SAS-12G with 40-Phy expander and 2 x 8i SAS Slimline connectors
|
Client Support
• MS Windows® 10, 8, 7, XP and Windows Server, Linux , FreeBSD, Solaris and Mac • Snap Shot Backup and Recovery Client Support • Active Directory, Rsync are supported
Remote Controls
• Power on/off, system reset + USB • IPMI, KVM over IP, Remote Power On/Off is supported
|
Indicators
• Power, LAN and HDD LEDs
Cooling
• 3 x 40 x 56mm hot-swap dual rotor fans for MB, 8 x 60 x 56mm dual rotor fans for Drives
|
Power Supply
• 2000W 1+1 redundant 80Plus Platinum power supply (AC input: 200-240V)
Operating Temperature
• From 0 °C to 40 °C (32°F to 104 °F)
|
Non-Operating Temperature
• From -10 °C to 60 °C (14°F to 140 °F)
Operating Humidity
• From 5% to 90% non-condensing relative humidity
|
Dimensions
• 4U Rackmount Chassis • 41" tool-less slide rail included • Option: Cable Management Kit • Dimensions: 19" W x 7" H x 41.3" D (434 x 175 x 1050mm) • Weight: 220 lb. (100kg) • Packaging: 468mm(18.4"H) x 616mm(24.3"W) x 1328mm(52.3"D),105kg (230 lb.) net
|
Warranty
• SAS, SATA-E Hard Driver , SSD carry 5 year • Base system:3 year standard parts and depot labor;lifetime toll free phone support. • Optional:3 or 5-year(total years) extended warranty with advanced parts replacement service. • Optional:7+year extended warranty service available. • On-site service is available with additional cost.
|
