Processor
• AMD EPYC™ 9005 series Processor
Memory
• 32 × DDR5 slots (RDIMM)，16-channel (8-channel per CPU), up to 5600MHz, support RDIMM/3DS RDIMM • Up to 8TB ECC
|
Storage
• Support 8 / 12× 3.5” or 24× 2.5” HDDs • Support 4 × U.2 NVMe SSD, 2× M.2 PCIe4.0×4/SATA SSD，2280/22110
Expansion Slot
• Up to 11 × standard expansion slots • Up to 8 × FHFL GPU Card • Support 1 × PCIe5.0 ×16 + 2 × PCIe4.0 ×8 (inaddition to 8 GPU)
|
Network
• Support 1×OCP3.0 expansion slot standard with PCIe 5.0 x8, (x16 is option) • LAN options: 4×1GbE / 2×10Gb SFP+ / 4×10Gb SFP+/ 2×25Gb SFP28 • Support NCSI
I/O
• 1 × VGA • 1 × COM • 2 × USB3.0 • 1 × IPMI RJ45 • 1 × Standard OCP NIC 3.0 slot
|
OS Support
Windows Server, Linux
Front Panel
• 2×USB3.0 • 1×Optional VGA
|
Internal I/O
• 2× USB 3.0 header、2×USB 2.0 header、1× USB 2.0 Type A • 1 × VROC Key header • 12 × SATA 3.0（3 × SFF-8643）, support RAID 0,1,5,10 • 3 × MCIO（PCIe 5.0x8），support 6 × NVMe（PCIe 5.0x4） • 2 × M.2 , PCIe 4.0 x4 , 2280 & 22110 • 12×4pin FAN • 1× VGA header for FP • 1×SPI TPM 2.0
Chassis
4U 19" Standard Rackmount
• 2.5” Configuration: W 448mm × H 175mm × D 772mm （792mm with ear bezel） • 3.5” Configuration: W 448mm × H 175mm × D 822mm （842mm with ear bezel）
|
Power Supply
• 4×Standard CRPS Power Modules，hot-swappable, support 2+2/ 3+1/ 1+1 redundancy • 1600W/2000W/2400W/2700W Platinum or Titanium power supply module option
Application
• GPU for AI, Deep Learning, HPC.
|
Environment
• Operating Temperature: +10 to +35 C • Non-operating Temperature: -40 to +70 C • Operating Relative Humidity: 10% to 80% (non-condensing) • Non-operating Relative Humidity: 10% to 93% (non-condensing) • MTBF: 100,000 Hours • FCC, CE, UL, RoHS Compliance
|
